Difficulty Level

Tools/Supplies Needed:

• phillips screwdriver
• nylon trim tool
• standard/flat screwdriver
• tape

Procedure:

• first remove the mirror cap which simply pulls straight off using a nylon trim tool
• wrap some tape around the tip of the standard screwdriver so it doesn't damage the plastic
• remove the phillips screw where the door panel closes against the dashboard
• remove the false speaker cover in front of the door handle which will expose a phillips screw
• to remove the false speaker cover, use a standard screwdriver to pop the front side out first and them the back side just unclips
• remove the phillips screw
• remove the plastic cap in the center of the door handle with the standard screwdriver which will also expose a phillips screw
• remove the phillips screw
• remove the small plastic expanding clip by the door latch on the door panel side
• open the armrest hatch and there will need to be one phillips screw removed on the front portion of the storage compartment
• to remove the window switch assembly, use a standard screwdriver both on the front and back portions releasing the clips and assisting the unit out
• disconnect the electrical connectors on the window switch assembly by depressing a tab and pulling straight off
• remove the phillips screw where the window switch assembly was located
• once all screws are removed, firmly grab the bottom of the door and pull door panel straight out
• you can use the assistance of a nylon trim tool
• once unclipped, open the door handle and assist the panel from the handle
• reassembly is reverse of disassembly

Frequently Asked Questions (FAQ):

Is this the same removal process for the passenger door panel?

Yes it is.
